Mower spare parts

#FA105980

Schröckenfux Mower blade 120 cm, 16 blades DIN 80, 4 pcs. Cleaning plates, instead of Agria 631374 Mower blade 120 cm, 16 blades DIN 80, 4 pcs. Cleaning plates, instead of Agria 631374

Mower blade with 16 blades suitable for the ESM centre cut finger bar mounted on Agria motorised implements with sliding block drive. The cutter head is attached to the blade on the reinforcement bar with 4 M8 screws at a distance of 101 and 177 mm. There are 4 cleaning plates on the mower blade. The cleaning plates are positioned above the 2nd, 6th, 11th and 15th blade.

€132.00*

#FA48799

Schröckenfux Mower blade 122 cm, 16 blades, 4 guide blades GB543, 2 threaded holes M8 with hole spacing 101 mm, instead of Vogel & Noot FG211400 Mower blade 122 cm, 16 blades, 4 guide blades GB543, 2 threaded holes M8 with hole spacing 101 mm, instead of Vogel & Noot FG211400

Mower blade for finger bar Vogel & Noot Plus mower. The mower blade has a length of 122 cm with 16 blades. There are 4 guide blades GB543 on the 2nd, 6th, 11th and 15th blade. The hole spacing of the M8 mounting holes is 101 mm.

€115.00*

#FA22545

Mower blade 135cm, 27 blades 59015, with 4 guide bars and smooth holder, 2 threaded holes M8, suitable for Aebi, BCS, Reform Mower blade 135cm, 27 blades 59015, with 4 guide bars and smooth holder, 2 threaded holes M8, suitable for Aebi, BCS, Reform

27 blades 59015, 6 guide strips, B590.59033.0

€79.00*

#FA21657

Mower blade 135cm, 27 blades, with serrated holder, instead of BCS & Reform B590.48906.0 Mower blade 135cm, 27 blades, with serrated holder, instead of BCS & Reform B590.48906.0

27 serrated blades, 6 guide rails, B590.48906.0

€79.90*

#FA919

Schröckenfux Mower blade 137 cm, 18 blades DIN 80, 4 pcs. Cleaning plates, instead of Agria 631375 Mower blade 137 cm, 18 blades DIN 80, 4 pcs. Cleaning plates, instead of Agria 631375

Mower blade with 18 blades suitable for the ESM centre cut finger bar mounted on Agria motorised implements with sliding block drive. The cutter head is attached to the blade on the reinforcement bar with 4 M8 screws at a distance of 101 and 177 mm. There are 4 cleaning plates on the mower blade. The cleaning plates are positioned above the 2nd, 7th, 12th and 17th blades.

€142.00*

#FA2314

Schröckenfux Mower blade 140cm, 18 blades DIN 80, instead of Agria 63-02-72 Mower blade 140cm, 18 blades DIN 80, instead of Agria 63-02-72

Total number of blades 18 pieces, 13 blades DIN 80, 5 blades 60-02-09, 4 cleaning plates 50-03-10

€119.00*

#FA48800

Schröckenfux Mower blade 140cm, 18 blades, 4 guide blades GB543, 2 threaded holes M8 with hole spacing 101 mm, instead of Vogel & Noot FG210400 Mower blade 140cm, 18 blades, 4 guide blades GB543, 2 threaded holes M8 with hole spacing 101 mm, instead of Vogel & Noot FG210400

Mower blade for finger bar Vogel & Noot Plus mower. The mower blade has a length of 140 cm with 18 blades. There are 4 guide blades GB543 on the 3rd, 7th, 12th and 16th blade. The hole spacing of the M8 mounting holes is 101 mm.

€119.00*

#FA44833

ESM Mower blade 142cm, 28 blades, for municipal cutter bar, instead of ESM 250.0210 Mower blade 142cm, 28 blades, for municipal cutter bar, instead of ESM 250.0210

Mower knife with 28 blades suitable for ESM municipal cutter bar with replaceable bottom knife.The knife head is attached to the knife with 2 M8 screws at a distance of 152.4mm.There are 6 pin holders on the mower knife to accommodate the rocker arms.The pin supports are positioned over 2nd/3rd, 6th/7th, 10th/11th, 18th/19th, 22nd/23rd, 26th/ 27. Blade.

€349.00*

#FA65860

Schröckenfux Mower blade 145cm 19 blades DIN 75 instead of Aebi AM46099/1 Mower blade 145cm 19 blades DIN 75 instead of Aebi AM46099/1

19 blades DIN 75, 4 cleaning plates AM23328/2 on 7th/8th. Blade, 5 outer blades on the right and left with sunk rivets at the top, driver plate 46092/1, 2 threaded holes M8, LA = 101 mm

€127.00*

#FA115729

Schröckenfux Mower blade 145cm 19 blades DIN 75 instead of Aebi AM46099/2 Mower blade 145cm 19 blades DIN 75 instead of Aebi AM46099/2

19 blades DIN 75, 6 cleaning plates AM23328/2 on 2nd, 5th, 8th, 12th, 15th and 18th blade, driver plate 46092/1, 2 threaded holes M8, LA=101 mm

€129.00*

#FA11811

ESM Mower blade 148 cm, 29 blades, for municipal cutter bar, instead of ESM 250.0120 Mower blade 148 cm, 29 blades, for municipal cutter bar, instead of ESM 250.0120

Mower blade with 29 blades suitable for ESM municipal cutter bars. The cutter head is attached to the blade with 2 M8x18 bolts at a distance of 101.6 mm. There are 6 pivot brackets on the cutter bar to hold the rocker arms. The pivot supports are positioned between the 2nd and 3rd, 7th and 8th, 11th and 12th, 18th and 19th, 22nd and 23rd and 27th and 28th blades.

€375.00*

NEU

#FA125005

Mower blade 158cm, 31 blades 59015, with 6 guide rails and smooth mounting, 2 threaded holes M8, suitable for Aebi, BCS, Reform Mower blade 158cm, 31 blades 59015, with 6 guide rails and smooth mounting, 2 threaded holes M8, suitable for Aebi, BCS, Reform

31 blades 59015, 6 guide bars, B590.59032

€105.00*

#FA133637

Mower blade 158cm, 31 blades, with serrated holder, instead of BCS & Reform B590.55050.0 and B590.58793 Mower blade 158cm, 31 blades, with serrated holder, instead of BCS & Reform B590.55050.0 and B590.58793

Mower blade suitable for BCS mowers and for AEBI and Reform mowers fitted with BCS cutter bars. The mower blade has 31 blades (563.50696) and 6 guide strips (563.59061). The guide strips are riveted onto the blade at the 2nd/3rd, 7th/8th, 12th/13th, 19th/20th, 24th/25th and 29th/30th blades. The cutter head is secured to the toothed drive plate with 2 M8 screws. The hole spacing is 76 mm.

€109.00*

#FA2039

Schröckenfux Mower blade 160cm, 21 blades DIN 75, instead of Aebi AM28294/1 Mower blade 160cm, 21 blades DIN 75, instead of Aebi AM28294/1

Mower blade suitable for Aebi cutter bars with additional cutting unit on the left and right side. The cutter bar has 21 DIN 75 blades with 4 cleaning plates AM8731/2. The cleaning plates are riveted onto the 8th, 9th, 13th and 14th blade. The rivets for the counter-blade of the additional cutting unit are ground on the left and right of 5 blades each. The cutter head is clamped onto the AM8880/1 drive plate. Austrian quality product

€127.00*

#FA52949

Schröckenfux Mower blade 160cm, 21 blades, 6 cleaning plates, 2 threaded holes M8, LA=122.5mm instead of Rapid 253012 Mower blade 160cm, 21 blades, 6 cleaning plates, 2 threaded holes M8, LA=122.5mm instead of Rapid 253012

The mower blade for the Rapid finger bar has 21 blades. There are 6 cleaning plates 14902 riveted onto the blades. The cleaning plates are fitted over the 2nd, 5th, 8th, 14th, 17th and 20th blades. There are two M8 threaded holes in the back of the blade with a hole spacing of 122.5 mm. The cutter head is attached to the mower blade in these threaded holes.

€105.00*

#FA126206

Schröckenfux Mower blade 160cm, 21 blades, 8 cleaning plates, 2 threaded holes M8, LA=122.5mm instead of Rapid 253012 Mower blade 160cm, 21 blades, 8 cleaning plates, 2 threaded holes M8, LA=122.5mm instead of Rapid 253012

The mower blade for the Rapid finger bar has 21 blades. There are 8 cleaning plates 14902 riveted onto the blades. The cleaning plates are fitted over the 2nd, 5th, 6th, 8th, 14th, 16th, 17th and 20th blades. There are two M8 threaded holes in the back of the blade with a hole spacing of 122.5 mm. The cutter head is attached to the mower blade in these threaded holes.

€115.00*

#FA7833

Schröckenfux Mower blade 165cm, 21 blades, instead of Steyr-PHANTOM 192720612 Mower blade 165cm, 21 blades, instead of Steyr-PHANTOM 192720612

Mower blade suitable for Steyr original Phantom cutter bars. The mower blade has 21 blades and is supplied complete with the cutter head 192720212.21 blades 192720252 serrated, 1 spring plate 192720295, 1 cutter head 192720212Austrian quality product

€195.00*

#FA2046

Schröckenfux Mower blade 175cm, 23 blades DIN 75, instead of Aebi AM27141/1 Mower blade 175cm, 23 blades DIN 75, instead of Aebi AM27141/1

23 blades DIN75, 2 cleaning plates AM8731/2

€125.00*

#FA7822

Schröckenfux Mower blade 18 blades suitable for STEYR T80 - 180 Mower blade 18 blades suitable for STEYR T80 - 180

18 blades DIN 80, 5 cleaning plates 1800 720 018, 1 knife head 180a 720056

€179.00*

#15179

Schröckenfux Mower blade 190cm, 25 blades DIN 75, instead of Aebi AM28289/1 Mower blade 190cm, 25 blades DIN 75, instead of Aebi AM28289/1

Version: gezahnt

25 blades DIN 75, 6 cleaning plates AM8731/2

€157.00*

#FA4714

Schröckenfux Mower blade 190cm, 25 blades DIN 80, instead of Bucher H150.043.790 Mower blade 190cm, 25 blades DIN 80, instead of Bucher H150.043.790

25 blades DIN 80, 6 blades DIN 80 recessed at the top, 4 cleaning plates

€115.00*

#FA7835

Schröckenfux Mower blade 200cm, 25 blades, instead of Steyr-PHANTOM 192720612 Mower blade 200cm, 25 blades, instead of Steyr-PHANTOM 192720612

Mower blade suitable for Steyr original Phantom cutter bars. The mower blade has 25 blades and is supplied complete with the cutter head 192720212.25 blades 192720252 serrated, 1 spring plate 192720295, 1 cutter head 192720212Austrian quality product

€215.00*

#FA16002

Schröckenfux Mower blade 230cm for Reform Metrac 2000, 2002, 2004, 3000 Mower blade 230cm for Reform Metrac 2000, 2002, 2004, 3000

Upper knife 30 blades, including 6 mushroom blades

€425.00*

#FA15998

Schröckenfux Mower blade 230cm for Reform Metrac 2000, 2002, 2004, 3000 Mower blade 230cm for Reform Metrac 2000, 2002, 2004, 3000

Bottom knife 31 blades, including 5 mushroom blades and 1 end blade

€398.00*
