Slurry compressor, slide valve
Rubber flange seal for 8' piston valve
With 2 fabric inserts for higher pressures, thickness 5 mm, 228x228x4 mm, hole spacing 180x180 mm.
Sealing ring 130x7mm for sight glass with bayonet lock
Sealing ring for sight glass with bayonet lock suitable for the MZ siphon lock. The inner diameter is 130mm and the thickness is 7mm.
Sealing ring 130x9.7mm for sight glass with ring closure
Sealing ring for sight glass with ring closure suitable for the MZ siphon lock. The inner diameter is 130mm and the thickness is 9.7mm.
Sealing ring 98x5.4mm for sight glass with internal thread
Sealing ring for sight glass with internal thread suitable for the MZ siphon lock. The inner diameter is 98mm and the thickness is 5.4mm.
Sealing ring for manure scraper with flange connection 4 5" 6", ø159 x 6,99 mm
The O-ring has the dimensions 159 x 6.99mm
Sealing ring for manure scraper with flange connection 8
The O-ring has the dimensions 206.6 x 6.99mm.
Sight glass without steel ring
including sealing ring
Siphon protection with straight connection
The siphon protection is used to protect the slurry compressor against the suction of slurry if there is no overflow protection or if it is out of order.
Slurry compressor MEC with gearbox and pressed lubrication
Battioni &~ Pagani vacuum pumps of the MEC series with transmission gears. The drive takes place via a cardan shaft with a maximum speed of 600 rpm. The ideal working speed is between 400 and 500 rpm.The slurry compressors are equipped with pressed lubrication, in which the required amount of lubricating oil can be manually adjusted using a drip oiler. The drip oiler is included in the scope of delivery and is roughly adjusted to the performance of the compressor at the factory. The setting should definitely be checked during operation and, if necessary, readjusted according to the information in the operating instructions.The scope of delivery includes: ~ ~ ~PTO shaft protection ~ ~ ~Drip oiler ~ ~ ~Oil lines ~ ~ ~Operating and maintenance instructionsThe pressure relief valve is not included in the scope of delivery!
STORZ replacement gasket
STORZ replacement gasketblack NBR rubber gasket suitable for Storz couplings
Straight flange socket with galvanised thread
Straight flange socket with external thread, galvanized version. Can be used as a transition from a manure slider with an internal thread to a flange connection from a quick coupler or another piston slider.Hole pattern flange: 150x150mm with 2" - 6" threadHole pattern flange: 180x180mm with 8" thread
Stuffing box 20x27x8mm for MZ manure scraper
Stuffing box seal 20x27x8mm for the slide rod of the manure slider with mechanical manual operation. 2 pieces are required for sealing.
Stuffing box nut with grease nipple
For use on sliders with lever set.
