Tractor parts

Suitable for Case: from 01/99 CS64/64A, CS68/68A, SC75/75A, CS78/78A, CS86/86A, CS94/94ASuitable for Steyr: 540, 545, 548, 650, 658, 760, 768, 870, 1090, 1100, 1108, 8060, 8070, 8080, 8090, 8045, 8055, 8065, 8075, 8095, 8100, 811 0, 8120, 8130, 8140, 8150, 8160, 8165, 8170, 942, 948, 955, 964, 970, 975, M968, M975, 9078, 9083, 9086, 9094, M9078, M9086, M9094

Suitable for Case JXU from 01/2002: 70, 80, 90, 100, New Holland L: 65, 75, 85, 95, TL from 01/1998: 70, 80, 90, 100, Ford New Holland: 4835, 5635 , 6635, 7635Can be used instead of Case-IH, Ford, New Holland: 1931162, 84399618,1930986, 47134379, 84592273

Suitable for Deutz: D4507C, 4807C, 6007C, 6207C, 6507C, 6807C, 6907C, 7007C, 7207C, 7807C, DX80, 85, 86, 90, 92, DX110 from 01/84, DX120 from 01 /84, DX140 from 01/84, DX 160 from 01/84, DX230 from 01/84, DX3.30, 3.50, 3.60, 3.65, 3.70, 3.80, 3.90, DX4.10, 4.17A, 4.30, 4.31, 4.50 , 4.51, 4.56, 4.57A, 4.61, 4.70, 4.71, 6.05, 6.06, 6.10, 6.16, 6.30, 6.50, 7.10, 8.30, Agrostar/Agrostar DX 4.61, 4.68, 4.71, 4.78, 6.0 8, 6.11, 6.21, 6.28, 6.31, 6.38, 6.61, 6.71, 6.81, 6.88, 8.31, Agroxtra DX 3.57, 4.07, 4.17, 4.57, 6.07

Suitable for Steyr: Hydraulic steering 1200, 8080 from VG.No. 8947, 942, 948, 955, 964, 968, M968, 970, 975, M975, 9078, M9078, 9083, 9086, M9086, 9094, M9094

Suitable for Fendt: Farmer 102, 103, 104, 105, 106, 108, Farmer 200S/SA, 201, 303LS, 304LS, 305S/LS/LSA, 306S/LS/LSA, 307S/LS /LSA, 308S/LS/LSA, 309S/LS/LSA, 310LS/LSA, 311LSA, 312LSA, F250GT, F255GT, F275GT/GTF, F345GT/GTM, F360GT/GTF/GTH, F365GTA, F380GT/GTA/GTF, F390GTA , F395GTA/GHA

Suitable for Steyr: Hydro steering 8060 from 01/80, 8070, 8075, 8100, 8120, 8140, 8150, 8160, 8170

Suitable for Deutz: D2506, 3006, 4006, 4506, 5006, 5206, 5506, 6006, 6206, 6806, 7006, 7206, 8006, 9006, 10006, 13006, 16006, D4007, 4507, 4807 , 5707, 6007, 6207, 6507, 6807, 6907, 7007, 7207, 7807, D4507C, 4807C, 5207C, DX 3.50, 3.60, 3.70, Intrac 2002, 2003, 2004, 2006, 6.05, 6.30, 6.60

Suitable for Fiat, New Holland: 45-66, 45-66S, 50-66, 55-66, 55-76F, 55-86F, 55-90, 60-66, 60-76, 60-85, 60-90, 60-93, 60-94, 62-86F, 65-66, 65-90, 65-93, 65-94, 90-90, 95-55, 1180, 1280, 1380, 1580, 1880, 100-90, 110-90, 115-90, 130-90, 140-90, 160-90, 180-90, Winner F100, F120, F130

Hydraulic oil based on high-qualityselective raffinates with active ingredients to improveoxidation resistance and corrosion protection.DIN 51 524/Part 2.

Hydraulic oil based on high-qualityselective raffinates with active ingredients to improveoxidation resistance and corrosion protection.DIN 51 524/Part 2.

Inner diameter: 35mmLength: 200mm ~

The hydraulic unlockable check valve prevents automatic adjustment and sinking under load. Scope of delivery: complete with connection hoses including plug and dust protection. Including hydraulically unlockable check valve (locking block).Piston K = 50mm, piston rod S = 25mm, up to approx. 70HP, pressure force 3534kg, pulling force 2650kg.The specified lengths always refer to the centre of the pin to the centre of the pin!

The hydraulic unlockable check valve prevents automatic adjustment and sinking under load. Scope of delivery: complete with connection hoses including plug and dust protection. Including hydraulically unlockable check valve (locking block).Piston K = 70mm, piston rod S = 35mm, up to approx. 120HP, pressure force 6927kg, pulling force 5195kg.The specified lengths always refer to the centre of the pin to the centre of the pin!

The installation length can be continuously adjusted using the attachment on the tractor side with an M30 thread (Cat.2). Scope of delivery: complete with connection hoses including plug and dust protection, chain for catch hook, top link ball. Including hydraulically unlockable check valve (locking block), without ball eye or swivel bearing.Piston K = 70 mm, piston rod S = 35 mm, up to approx. 100 HP, pressure force 6927 kg, pulling force 5195 kg.The length refers to the bolt centre of the hook to the end of the screw-in sleeve!

Complete with connection hoses, timing chain for catch hook, top link ball and stroke indicator. Including hydraulically unlockable check valve (locking block).Piston K = 63mm, piston rod S 36mm up to approx. 90HP, pressure force 5600kg, pulling force 3900kg.The specified lengths always refer to the centre of the pin to the centre of the pin!

Scope of delivery: complete with connection hoses including plug and dust protection, chain for catch hook, top link ball. Including hydraulically unlockable check valve (locking block).Piston K = 70mm, piston rod S = 35mm, up to approx. 120HP, pressure force 6927kg, pulling force 5195kg.The specified lengths always refer to the centre of the pin to the centre of the pin!

Scope of delivery: complete with connection hoses including plug and dust protection, chain for catch hook, top link ball. Including hydraulically unlockable check valve (locking block).Piston K = 80mm,Piston rod S = 40mm, up to approx. 160 HP, pressure force 9047kg, pulling force 6785kg.The specified lengths always refer to the centre of the pin to the centre of the pin!

Hydraulic top link with cat. 3 catch hook and articulated head support. Particularly suitable for mounting heavy implements. The top link is supplied with a hydraulically unlockable non-return valve (locking block). The connection hoses are complete with plug, dust protection and the appropriate screw-in connector for the locking block. The actuation chain for the catch hook and the top link ball are included in the scope of delivery. Suitable for tractors up to approx. 250 hp, piston Ø K = 90 mm, piston rod Ø S = 45 mm, pushing force 11451 kg, pulling force 8588 kg.The specified lengths always refer to the centre of the pin to the centre of the pin!

Hydraulic top-link with hook Cat.3 and joint head. Particularly suitable for mounting heavy equipment. Including hydraulically unlockable check valve (locking block).Suitable for tractors up to approx. 200 HP, piston K = 80mm, piston rod S = 40mm, pressure force 9047kg, pulling force 6785kg.The specified lengths always refer to the centre of the pin to the centre of the pin!

Suitable for tractors up to approx. 250 HP, piston K = 90mm, piston rod S = 45mm, pressure force 11451kg, pulling force 8588kg. With CBM catch hook Cat.3 including ball Cat. 3 32.2mm. Including hydraulically unlockable check valve (locking block), 2 hydraulic hoses with plug and dust caps, actuation chain for catch hook, top link bracket and lift indicator.Indication of the installation length including joint head.The specified lengths always refer to bolt centre to bolt centre including the knuckle !

Suitable for tractors up to approx. 250hp, piston K = 90mm, piston rod S = 40mm, pressure force 11451kg, pulling force 9150kg. Suitable for Fiat, Ford, New Holland and Steyr Profi. CBM catch hook cat. 3, with ball cat. 3/2 25mm. Including hydraulically unlockable check valve (locking block), 2 hydraulic hoses with plug, actuation chain for catch hook, top link bracket and lift indicator.Indication of the installation length including joint head.The specified lengths always refer to bolt centre to bolt centre including the knuckle !

Affordable hydraulic lower link adjustment for easy self-assembly. On slopes or tight curves, the entire three-point linkage can be moved laterally by up to 270 mm (depending on the tractor type) while driving. This means that, for example, when mowing on slopes, the incorrect cut, whether mowed twice or not mowed, can be compensated for by the mower drifting away. This investment is worth it with the first use.With M30x3.5mm internal thread in the piston rod for use on most tractors/trailers.Stroke 100 mm, installation length 345 mm, ball eye inner diameter 25.4 mm, outer cylinder diameter 105 mm, piston rod diameter 50 mm, hydraulic connections G1/2".Scope of delivery: hydraulic side brace as shown.Assembly: connect to a double-acting control valve with 2 hose lines.

Aussendurchmesser: 85 mmGesamtlänge: 80 mm

Innendurchmesser: 85 mmAussendurchmesser: 97 mmLänge: 241 mm
