Agricultural machinery

To close a hydraulic connection, ie a double-acting cylinder becomes a single-acting cylinder.

Surface untreated.

According to DIN 2353, for pipe connection.

According to DIN/ISO228.

Colour blue

​Mechanical actuation with spring return as standard. The neutral position is achieved via a pressure-free return circuit, and ports A & B are connected to the reservoir. Pressure relief valve on port P (pump). Negative overlap of the spools.Standard configuration of the valves in parallel.Max. flow rate: 45 L/min.Operating pressure: 250 barMax. pressure: 320 barPressure relief valve set to: 140 bar, adjustable from 100–250 barThreaded connections A, B, P, T: R3/8″Threaded connections P2, T2: R1/2″H-R = Lift engaged, SW = Neutral position – float position, S = LowerThe switching positions listed depend on the specific model of the control valve.

Mechanical actuation with spring return as standard. The middle position is designed with a pressureless circulation and the ports A &~ B are blocked. Pressure relief valve at connection P (pump). Negative overlap of the slides.Standard version of the valves in parallel connection.Design: BM70Flow max.: 80L/minOperating pressure: 250 barmax. Pressure: 320 barRelief valve set: 140 bar, adjustable from 100-250 barScrew-in thread A, B, P, T,: R1/2?Screw-in thread P2, T2: R3/4?H-R = Lift (locked), SW = Centre position – float position, S = Lower.The switching positions listed depend on the respective model of the control valve.

Suitable for type 110, 111, 111S, 112, 112K, 115, 131 from 1976.

20mm

Bore 12mm, length 99mm

Bore 12 mm, length 70 mm

Total length: 136 mmDiameter: 25 mm

M16x2x100 mm bolt with lock nut, strength 10.9, thread length 40 mm. Suitable for Agricom, Ferri, Gaspardo, Kverneland, M.E.A.A.T., Maletti, Maschio and Votex.

Bolt with tab galvanized, there is an additional hole in the tab to secure the bolt against twisting or loss

Suitable for Steyr 80 series with Bosch alternator 33AReplacement regulator for common Bosch alternators

Suitable for BUSATIS mower Bidux 1205

Knife holder for lower knife guide arm for riveting. Suitable for Busatis double knife mower BM 321KW, BM 1102, BM1124, BM1260.

Suitable for BUSATIS mower BM 1102, BM 1124, BM 1135 and BM 1260. Original ESM spare part.

Lens: Clear, right/left
