Pressure force 5089 kg, tensile force 2826 kg at 180 bar, connection G 3/8, nominal pressure 250bar
Pressure force 6927 kg, tensile force 4665 kg at 180 bar, connection G 3/8, nominal pressure 250bar
Bolt d=35 mm, connection G=R1/2", T=61 mm, U=25 mm, pressure force 9047 kg, tensile force 5513 kg at 180 bar, nominal pressure 250 bar.
Pressure force 9047 kg, tensile force 5513 kg at 180 bar, connection G 1/2, nominal pressure 250bar
15-piece tool set with hand pump and extensive accessories. Weight 32kg. Quick tool change thanks to plug connection. In PVC carrying case.
Average rating of 5 out of 5 stars
Especially for retrofitting mechanical front loaders with hydraulic actuation of the tools. In conjunction with a EURO quick-change frame, a fully hydraulic front loader can be created in a very short time (see front loader conversion kit Faie No. 70599). With the 895 mm long tilting linkage and the lifting path of 507 mm, a tilt angle of up to 180 can be achieved.The scope of delivery includes 1 hydraulic hose with union nut M18x1.5 / 12L in lengths of 1100 mm and 1300 mm included.Pressure force per cylinder 6927 kg at 180 barTensile force per cylinder 5195 kg at 180 barTilt angle up to 180 Stroke path 507 mm
Can be used instead of man: WH980/3Outer diameter: 98mmLength: 239mmThread: 1 3/8"-12 UNF
Average rating of 5 out of 5 stars
Very stable hydraulic fruit press. Also suitable as a berry press. Basket, drip tray and press disc made of stainless steel. Solid powder-coated steel frame. Incl. hydraulic cylinder, filter cloth and shims Technical data:12 liter version: 35x45x61 cm, press basket 250x240 mm (xH), 25 kg. 2 t26 liter version: 40x48x64 cm, press basket 305x330 mm (xH ), 30 kg, 2 t50 liter version: 45x55x84 cm, press basket 355x500 mm (xH), 40 kg, 2 t
Hydraulic hand pumps are used in hydraulic systems where only one hydraulic movement is required. These are mostly simple systems where high pressure with low flow rate is required, such as bending tools, lifting devices, tipping devices for car trailers and smaller agricultural trailers, etc. Hand pumps are a simple and inexpensive solution for operating double-acting hydraulic cylinders. The extension and retraction of the hydraulic cylinder is controlled by the integrated 4-3 directional control valve.The hand lever is included.Connection thread: 3/8" BSP internal thread
Hydraulic hand pumps are used in hydraulic systems where only one hydraulic movement is required. These are mostly simple systems where high pressure with low delivery capacity is required, such as bending tools, lifting devices, tipping devices for car trailers and smaller agricultural trailers, etc. Hand pumps are a simple and inexpensive solution for operating single-acting hydraulic cylinders. The hydraulic cylinder is retracted by opening the drain cock and using the weight of the load.The hand lever is included.Connection thread: 3/8" BSP internal thread
For universal use in agriculture and industry. The simple and inexpensive solution for operating hydraulic cylinders.
For universal use in agriculture and industry. The simple and inexpensive solution for operating hydraulic cylinders.
Single-acting with return spring, swiveling, lifting force at 150 bar: 4.9 tons. max. 250bar, temperature range: -25C to +80C, dimensions A: 65mm, B: 70mm, C: 80mm, E: 400mm, P 1/2" (BSP), M: 54mm, N: 230mm, G: 8mm, stroke 190mm
Single-acting with return spring, swiveling, lifting force at 150 bar: 8.5 tons. max. 250 bar, temperature range: -25C to +80C, dimensions A: 85mm, B: 90mm, C: 100mm, E: 430mm, P 1/2" (BSP), M: 54mm, N : 230mm, G: 8mm, stroke 230mm
Average rating of 5 out of 5 stars
Single-acting with return spring R1/2?, swiveling.Lifting force 100 bar: 5.67 t, 150 bar: 8.5 t.
With side connections R 3/8?, shaft 16 mm, max. inlet pressure 140 bar.
Connections R 1/2?, shaft 25 mm, plain bearing.
Connections R 1/2?, shaft 32 mm, plain bearing.
With side connections R 1/2?, shaft 25 mm, with tapered roller bearings.
Average rating of 4.8 out of 5 stars
Universal lubricating head nozzle with thread M10x1, Made in Germany
Average rating of 5 out of 5 stars
Suitable for Case: from 01/99 CS64/64A, CS68/68A, SC75/75A, CS78/78A, CS86/86A, CS94/94ASuitable for Steyr: 540, 545, 548, 650, 658, 760, 768, 870, 1090, 1100, 1108, 8060, 8070, 8080, 8090, 8045, 8055, 8065, 8075, 8095, 8100, 811 0, 8120, 8130, 8140, 8150, 8160, 8165, 8170, 942, 948, 955, 964, 970, 975, M968, M975, 9078, 9083, 9086, 9094, M9078, M9086, M9094
Suitable for Case JXU from 01/2002: 70, 80, 90, 100, New Holland L: 65, 75, 85, 95, TL from 01/1998: 70, 80, 90, 100, Ford New Holland: 4835, 5635 , 6635, 7635Can be used instead of Case-IH, Ford, New Holland: 1931162, 84399618,1930986, 47134379, 84592273
Suitable for Deutz: D4507C, 4807C, 6007C, 6207C, 6507C, 6807C, 6907C, 7007C, 7207C, 7807C, DX80, 85, 86, 90, 92, DX110 from 01/84, DX120 from 01 /84, DX140 from 01/84, DX 160 from 01/84, DX230 from 01/84, DX3.30, 3.50, 3.60, 3.65, 3.70, 3.80, 3.90, DX4.10, 4.17A, 4.30, 4.31, 4.50 , 4.51, 4.56, 4.57A, 4.61, 4.70, 4.71, 6.05, 6.06, 6.10, 6.16, 6.30, 6.50, 7.10, 8.30, Agrostar/Agrostar DX 4.61, 4.68, 4.71, 4.78, 6.0 8, 6.11, 6.21, 6.28, 6.31, 6.38, 6.61, 6.71, 6.81, 6.88, 8.31, Agroxtra DX 3.57, 4.07, 4.17, 4.57, 6.07
