Agricultural machinery

for reversing video color TFT 7

1.5 mm with 1 plug and 1 coupling socket, 7-pin.

1.5 mm with 2 plugs, 7-pin.

Cable cross section 7 x 1.5 mm with 2 plugs, 7-pin, plastic.

with 13-pin plug and 5-pin bayonet

with 7-pin plug, 2x 3.0 m DC outlet, 5-pin. bayonet

Cross section 2.5 mm, length 3.2 m

with 13-pin plug, 2x 3.0 m DC outlet, 5-pin. bayonet

Set including seal and screwsVersion: old

Connection thread: M10x1

Hole spacing from two-hole flange: 78 mm

for 4 cylinders, hole spacing = 84 mm

This connection plate is fitted as a replacement for the gearbox cover. The plate has 4 hydraulic connections on the top for P=pump, R=return, W=pressure transfer and Z=additional lift cylinder. This plate makes it possible to connect an externally mounted control unit. If no control valve with pressure transfer line is used, the W connection is closed. In order to guarantee the function of the tractor hydraulics with this installation, a shut-off-valve is fitted in the pressure line between connection P and the control valve. This must be closed when the three-point hydraulic system is used. This prevents pressure from escaping via the tank line of the additionally installed control valve.If a mobile control valve with pressure transfer line is used, connection W is connected to the pressure transfer line connection on the mobile control valve. This allows the tractor hydraulics and the mobile control valve to be used simultaneously. No shut-off-valve is required!Can be used in hydraulic systems of Ford tractor systems 3000, 4000, 5000.Max. Operating pressure: 250 barNominal flow rate 70 l/minTightening torque 78 Nm Connections M18x1.5 Dimensions (LxWxH): 160 x 130 x 20 mm

Consisting of 2 pieces of connection parts with internal thread and 1 piece of blind cap.2 pieces of straight connections

Consisting of 2 pieces of connection parts with internal thread and 1 piece of blind cap.1 piece straight and 1 piece 90 connection

Consisting of 2 connecting parts with internal thread and 1 blind cap.2 pieces 90

M18x1.5 external thread.

R1/2"~ BSP external thread with 60 cone

Expand your Connix set with two new front lights!  ~Perfect for use with front weights or other front mounted equipment. Simply connect the front lights to the radio transmitter of your existing Connix set can be carried out."PAIRING" code/alignment: 7-pin. Plug in the transmitter, turn on the ignition, press the pairing buttons on the lights at the same time for 5 seconds. press. ~  ~  ~  ~  ~ ~

Brake light, tail light, indicator, license plate light, with magnet (no StVZO approval)Simply connect the tail lights to the radio transmitter of your existing Connix set.TIP: In order to connect the tail light to the existing light set, a code comparison must be carried out "PAIRING" must be carried out in advance."PAIRING" code/alignment: 7-pin. Plug in the transmitter, turn on the ignition, press the pairing buttons on the lights at the same time for 5 seconds. press. ~  ~  ~  ~  ~  ~  ~  ~  ~  ~  ~  ~ ~

With 4 functions: brake light, tail light, indicator, license plate lightwireless, magnetic, rechargeableChange between machines and vehicles in seconds without toolsdurable, developed for agricultureConsisting of: right tail light, tail light left, 7-pin Plug, transmitter/transmitterCAN bus compatible, battery, charging cable, EMC, ECE10, RoHS, IP65, -20C/+50C, 12V(no StVZO approval)

magnetic, wireless, rechargeable, with monitoring display/sensorIndicator with neon light effect, modern design with clear and bright lightWith 6 lighting functions: tail light, indicator, brake light, license plate light, rear fog light and triangle reflectorThe display sensor for 12V socket is wirelessly connected to the radio light and provides information about the function and battery charge level of the lights while driving.Simply plug the display sensor into the vehicle's 12 V socket. An additional comfort that also provides additional security.The ConniX Plus is bright, simple, unique and equipped with intelligent technology. It is the first choice for wireless lighting solutionsSwitch between different vehicles and machines in seconds. Consisting of: rear light right, rear light left, 7-pin. Plug, transmitter/transmitter, display sensor, battery charging cable, 12V, up to 10 hours battery life, ECE R10, RoHS, IP65, -20C/+50C, transmission max. 20m, (not StVZO approved )

Use for the driving clutch pedal
