Agricultural machinery

sealing kit

​Suitable for the following Bosch injection pumps: 0460303151, 0460304228, 0460304236, 0460304237,0460306126, 0460306156, 0460306156, 0460306188, 0460306224, 0460393006, 0460393007, 0460306008, 0460393035

Cuff for the gear levers ~

1 liter (for spur gears)

​For various types of application, especially in agriculture. Small dimensions and low weight. Easy maintenance. The gearboxes are supplied without oil filling. General technical data: Inlet connection: 1 3/8" Output connection: Ø 35 h6 Reversal of direction of rotation: yes In general, torque peaks up to 2 times the nominal torque do not cause damage to the individual gearbox components. However, complete integrity can only be guaranteed by a suitable safety device.

In agricultural technology, scraper floors are often driven with a hydraulic drive via an oil motor in conjunction with a scraper floor gear. These drives can be found in loading wagons, manure spreaders and also in chopping wagons. For this purpose, gearboxes with a high reduction ratio and a high transferable torque are used. The gearboxes are supplied with different diameters for the drive shaft. A hydraulic motor with a shaft diameter of 25 mm and an SAE-A flange is used on the input side. The design of the hydraulic motor depends on the required speed of the scraper floor shaft and the available liter output of the hydraulic pump. In general, torque peaks of up to 2 times the nominal torque do not cause any damage to the individual gear components. However, complete integrity can only be guaranteed by a suitable safety device.Delivery without oil motor!

In agricultural technology, scraper floors are often driven with a hydraulic drive via an oil motor in conjunction with a scraper floor gear. These drives can be found in loading wagons, manure spreaders and also in chopping wagons. For this purpose, gearboxes with a high reduction ratio and a high transferable torque are used. The gearboxes are supplied with different diameters for the drive shaft. A hydraulic motor with a shaft diameter of 25 mm and an SAE-A flange is used on the input side. The design of the hydraulic motor depends on the required speed of the scraper floor shaft and the available liter output of the hydraulic pump.In general, torque peaks of up to 2 times the nominal torque do not cause any damage to the individual gear components. However, complete integrity can only be guaranteed by a suitable safety device.Delivery without oil motor!

Maximum power transmission for professionals: Bondioli & Pavesi S2050 gearboxesWhen it comes to absolute reliability in continuous operation, farmers and machine builders worldwide rely on drive technology from Bondioli & Pavesi. With the S2050 series right-angle gearboxes, you get robust solutions made of high-quality grey cast iron, specially developed for the toughest mechanical requirements.Why the S2050 series?These gearboxes form the backbone of many agricultural machines – from feed mixers to soil cultivation equipment. They impress with:Maximum load capacity: Thanks to their solid grey cast iron housings, these models offer outstanding stability and vibration damping.Precise performance: The S2050 is the all-rounder for medium loads with an input power of up to 28 kW (38 hp) at 540 rpm.Versatile gear ratios: With common gear ratios (e.g. 1.91:1 or 1:1), the gearboxes can be precisely adapted to your machine requirements.Durability through quality: Developed to the highest industry standards for minimal maintenance intervals and maximum service life.Technical highlights at a glance, transmission ratio 1,46:1Max. power (540 rpm)        approx. 28 kW / 38 hpMax. output torque    up to 722 Nm (at 540 rpm)Material                    High-quality grey cast ironApplication                Fertiliser spreaders, small mowersEnsure original quality for your drive!Whether as original equipment or as a durable spare part, with Bondioli & Pavesi you are choosing efficiency and safety in the field.

Maximum power transmission for professionals: Bondioli & Pavesi S2050 gearboxesWhen it comes to absolute reliability in continuous operation, farmers and machine builders worldwide rely on drive technology from Bondioli & Pavesi. With the S2050 series right-angle gearboxes, you get robust solutions made of high-quality grey cast iron, specially developed for the toughest mechanical requirements.Why the S2050 series?These gearboxes form the backbone of many agricultural machines – from feed mixers to soil cultivation equipment. They impress with:Maximum load capacity: Thanks to their solid grey cast iron housings, these models offer outstanding stability and vibration damping.Precise performance: The S2050 is the all-rounder for medium loads with an input power of up to 49 kW (66 hp) at 540 rpm.Versatile gear ratios: With common gear ratios (e.g. 1.91:1 or 1:1), the gearboxes can be precisely adapted to your machine requirements.Durability through quality: Developed to the highest industry standards for minimal maintenance intervals and maximum service life.Technical highlights at a glance, transmission ratio 1:1Max. power (540 rpm)        approx. 49 kW / 66 hpMax. output torque    up to 859 Nm (at 540 rpm)Material                    High-quality grey cast ironApplication                Fertiliser spreaders, small mowersEnsure original quality for your drive!Whether as original equipment or as a durable spare part, with Bondioli & Pavesi you are choosing efficiency and safety in the field.

Maximum power transmission for professionals: Bondioli & Pavesi S2050 gearboxesWhen it comes to absolute reliability in continuous operation, farmers and machine builders worldwide rely on drive technology from Bondioli & Pavesi. With the S2050 series right-angle gearboxes, you get robust solutions made of high-quality grey cast iron, specially developed for the toughest mechanical requirements.Why the S2050 series?These gearboxes form the backbone of many agricultural machines – from feed mixers to soil cultivation equipment. They impress with:Maximum load capacity: Thanks to their solid grey cast iron housings, these models offer outstanding stability and vibration damping.Precise performance: The S2050 is the all-rounder for medium loads with an input power of up to 29 kW (39,44 hp) at 540 rpm.Versatile gear ratios: With common gear ratios (e.g. 1.91:1 or 1:1), the gearboxes can be precisely adapted to your machine requirements.Durability through quality: Developed to the highest industry standards for minimal maintenance intervals and maximum service life.Technical highlights at a glance, transmission ratio 1:1,91Max. power (540 rpm)        approx. 29 kW / 39,44 hpMax. output torque    up to 272 Nm (at 540 rpm)Material                    High-quality grey cast ironApplication                Fertiliser spreaders, small mowersEnsure original quality for your drive!Whether as original equipment or as a durable spare part, with Bondioli & Pavesi you are choosing efficiency and safety in the field.

Maximum power transmission for professionals: Bondioli & Pavesi S2100 gearboxesWhen it comes to absolute reliability in continuous operation, farmers and machine builders worldwide rely on drive technology from Bondioli & Pavesi. With the S2100 series gearboxes, you get robust solutions made of high-quality grey cast iron, specially developed for the toughest mechanical requirements.Why the S2100 series?These gearboxes form the backbone of many agricultural machines – from feed mixers to soil cultivation equipment. They impress with:Maximum load capacity: Thanks to their solid grey cast iron housings, these models offer outstanding stability and vibration damping.Precise performance: The S2100 is a powerhouse for demanding tasks, delivering up to 81 kW (110 hp) at 540 rpm in a 1:1 transmission ratio, or an impressive 125 kW (170 hp) at 1000 rpm.Versatile gear ratios: With common gear ratios (e.g. 1.91:1 or 1:1), the gearboxes can be precisely adapted to your machine requirements.Durability through quality: Developed to the highest industry standards for minimal maintenance intervals and maximum service life.Technical highlights at a glance, transmission ratio 1:1Max. power (540 rpm)        approx. 81 kW / 110 hpMax. output torque    up to 1431 Nm (at 540 rpm)Material: High-quality grey cast ironApplication: Mulchers, larger tillers, feed mixersEnsure original quality for your drive!Whether as original equipment or as a durable spare part, with Bondioli & Pavesi you are choosing efficiency and safety in the field.

Maximum power transmission for professionals: Bondioli & Pavesi S2100 gearboxesWhen it comes to absolute reliability in continuous operation, farmers and machine builders worldwide rely on drive technology from Bondioli & Pavesi. With the S2100 series gearboxes, you get robust solutions made of high-quality grey cast iron, specially developed for the toughest mechanical requirements.Why the S2100 series?These gearboxes form the backbone of many agricultural machines – from feed mixers to soil cultivation equipment. They impress with:Maximum load capacity: Thanks to their solid grey cast iron housings, these models offer outstanding stability and vibration damping.Precise performance: The S2100 is a powerhouse for demanding tasks, delivering up to 51 kW (69 hp) at 540 rpm in a 1:1,92 transmission ratio, or an impressive 79 kW (107 hp) at 1000 rpm.Versatile gear ratios: With common gear ratios (e.g. 1.91:1 or 1:1), the gearboxes can be precisely adapted to your machine requirements.Durability through quality: Developed to the highest industry standards for minimal maintenance intervals and maximum service life.Technical highlights at a glance, transmission ratio 1:1,92Max. power (540 rpm)         approx. 51 kW / 69 hpMax. output torque     up to 474 Nm (at 540 rpm)Material:  High-quality grey cast ironApplication:  Mulchers, larger tillers, feed mixersEnsure original quality for your drive!Whether as original equipment or as a durable spare part, with Bondioli & Pavesi you are choosing efficiency and safety in the field.

With 5 different possible uses.1) Input X, output Y: Reduction 2:1 with reversal of direction of rotation 2) Input Reduction 2:1 with constant direction of rotation 3) Input Z (Y), output Y (Z): Ratio 1:1 with reversal of direction of rotation < strong>4) Input Y, output X: Ratio 1:2 with reversal of direction of rotation 5) Input Z, output Direction of rotation. Technical data: 14.7 kW, 540 rpm or 1000 rpm, Connections: 3x13/8x6 (inner profile). 1 piece of PTO shaft stub (as shown) included in delivery. A mounting console is attached to the gearbox. Filled with gear slime EPO-0.3 kg.In general, torque peaks of up to 2 times the nominal torque do not cause any damage to the individual gear components. However, complete integrity can only be guaranteed by a suitable safety device.

Unassembled, consisting of gimbal ring, lever mechanism, rivet set.

12V 1.2W, socket W2x4.6d

12V, 5W socket W2, 1x9.5d

The gliding sole with holder replaces the cast outsole 341.0120 and 341.0130.

The base funnel is made of hard PVC and gives the protection the necessary strength and durability. The sliding protective tubes are made from high-strength injection molded plastic. The retaining chain prevents the accident protection from rotating together with the drive shaft. (Length is measured from center of cross to center of cross).

Bore diameter: 26mm

Screw-in thread: 1/2 inch
