Agricultural machinery

Inexpensive 103-piece eyelet assortment including assembly tools. Contents: 50 pieces of eyelets 10x20x6 mm, 50 pieces of eyelet washers 10x20x6 mm and 1 piece each of punch, anvil and impact punch

Suitable for plow bodies M300, M350, U10, U13, U15, UN300, UN350, UN400, UN430, UST400, W25, W35, W300, WS13, WSU350, WS350, WY350, WS400, WY400, Y25

260 pieces, in a practical PVC case. Indispensable for everyday needs. Contents: Folding cotter pins, spring cotter pins, split pins, heavy-duty clamping sleeves, locking rings, sealing rings, tension springs, compression springs in various sizes.

Heavy version suitable for Einbck, Heger, Howard, Jeitler, Kocke, Landsberg-Pttinger, Regent, Vogel &~ Noot. Hardness 48-50 HRC, radius 300 mm, working width 130 mm.

Heavy version suitable for Einbck, Heger, Howard, Jeitler, Kocke, Landsberg-Pttinger, Regent, Vogel &~ Noot. Hardness 48-50 HRC, radius 300 mm, working width 180 mm.

Simple and quick coupling and uncoupling of implements on Category 2 and 3 front loaders. The upper mounting bolts enable individual tilt angle adjustment by repositioning. The quick-change frame also has a mechanical central locking system. Locating bolt on the front loader side 30 mm, receiving shaft on the device side 40 mm, mounting width of the front loader swing arm inside minimum 855 mm and outside max. 1120 mm, locking bolt 20 mm, total width 1159 mm, weight 59 kg. With a load center of 800 mm, the load capacity is approx. 3000 kg.The quick-change frame in conjunction with hydraulic actuation enables a cost-effective conversion to a fully hydraulically controlled modern loader. This opens up a wide range of new areas of application for your old front loader. With the EURO attachment you increase the impact power and expand the possible uses of your old front loader in many areas.

Simple and quick coupling and uncoupling of implements on Category 2 front loaders. The upper mounting bolts enable individual tilt angle adjustment by repositioning. The quick-change frame also has a mechanical central locking system. Locating bolt on the front loader side 30 mm, receiving shaft on the device side 40 mm, mounting width of the front loader swing arm inside minimum 860 mm and outside max. 1120 mm, locking bolt 20 mm, total width 1159 mm, weight 60 kg. With a load center of 800 mm, the load capacity is approx. 3000 kg.The quick-change frame in conjunction with hydraulic actuation enables a cost-effective conversion to a fully hydraulically controlled modern loader. This opens up a wide range of new areas of application for your old front loader. With the EURO attachment you increase the impact power and expand the possible uses of your old front loader in many areas.

Simple and quick coupling and uncoupling of implements on category 2 and 3 front loaders. The upper mounting bolts enable individual tilt angle adjustment by repositioning. Locating bolt on the front loader side 30 mm, receiving shaft on the device side 40 mm, mounting width of the front loader swing arm inside minimum 860 mm and outside max. 1120 mm, locking bolt 20 mm, total width 1159 mm, weight 60 kg. With a load center of 800 mm, the load capacity is approx. 3000 kg. Hydraulic locking with a double-acting cylinder. Includes 1.5 m hose with connection M18x1.5/12L union nut.

Simple and quick coupling and uncoupling of implements on Category 2 front loaders. The upper mounting bolts enable individual tilt angle adjustment by repositioning. The quick-change frame also has a mechanical central locking system. Locating bolt on the front loader side 30 mm, receiving shaft on the device side 40 mm, mounting width of the front loader swing arm inside minimum 860 mm and outside max. 1120 mm, locking bolt 20 mm, total width 1159 mm, weight 60 kg. With a load center of 800 mm, the load capacity is approx. 3000 kg. The side locking can be easily converted from the right side to the left side by loosening 2 screws.The quick-change frame in conjunction with a hydraulic actuation enables a cost-effective conversion to a fully hydraulic one controlled modern loader. This opens up a wide range of new areas of application for your old front loader. With the EURO attachment you increase the impact power and expand the possible uses of your old front loader in many areas.

outside 390mm, inside 27mm, holes 8 mm

8-wing, hole diameter: 9mm, hole spacing: diagonal 65mm, outer : 415 mmsuitable for water pump order no. 63142

bladesCentering hole: 40mmOuter diameter: 410mm

4 wings

Soft start and temperature-dependent speed control of the fan. The maximum starting current is approx. 10% above the rated fan current. The fan speed is varied depending on the oil temperature using a temperature sensor (accessory). Overload and reverse polarity protection on voltage input. Time-delayed fan activation for self-protection. Control range with temperature sensor 45-55C, switching point with temperature switch 50C. Includes adapter cable for temperature switch (61128, 77617) or sensor (61127, 77616) with plug.

​Outer diameter: 77 mmLength: 226 mmShaft diameter: 8 mmPower consumption: 80 watts Voltage: 12 V

Fan motor complete with housing, sealing profiles and fastening material suitable for asa oil cooler type 0176/0177/0256/0257, TT16, TT25By using a fan controller, the maximum charging and discharging current (ripple current) can be kept at the maximum value of 1%.Temperature range from -20 °C to 80 °CScope of delivery: 1 pc. Fan motor complete with housing, 4 pcs. screws with nuts and washers, 4 pcs. Spacers, 2 pcs. sealing profiles

Tensile load approx. 4300 kg, with bolt 18 mm and spring cotter pin.

Faster leakage oil drain connection T-piece

Faster leak oil drain housing TARV simply with dust cap. The leakage oil drain connection is designed at 45.
